Residential Telephone Entry
System
General Specifications
Linear’s
residential telephone entry system is the first to
utilize cast stainless steel for its inherent
strength and striking appearance. This housing can
take hits from both Mother Nature and vandals and
maintain its functional integrity and good looks. As
an alternative to this stainless housing, the RE-1
and RE-2 also come in cast zinc with a powder coated
nickel finish. White down lighting that is both
dramatic and practical is provided by an extremely
long-life white LED source. The use of surface mount
technology (SMT) for all electronic components
minimizes the effects of interference from electro
static discharge and protects against damage from
lightning strikes.
The call forwarding feature allows a visitor to
contact the resident at a programmed telephone
number instead of through the on-site telephones.
The feature can be set to be active during a
selected time (set with the system’s
seven unique time zone schedules) or at all times.
The telephone number programmed can contain an
extension number and an optional time delay before
dialing the extension. The call forwarding feature
can also be set to call the on-site telephones
first, then if there’s
no answer, place a call to the programmed forwarding
telephone number. During the forwarded call, the
access relays can be controlled simply by using the
telephone’s
keypad.
STANDARD EQUIPMENT
RE-1 and RE-2: residential telephone entry systems
that are capable of sharing an existing phone line,
a dedicated line, and dialing out up to 3 additional
off site numbers or used as an intercom; integral
keypad used to accept entry codes; integral radio
receiver will accept signals from block coded
transmitters; built-in clock calendar; voice
prompts; accepts one remote keypad; provisions for
dealer installed (not included) Knox switch;
telephone bypass switch
AVAILABLE ACCESSORIES
RE-BWC: RE-1 field upgradable black & white CCTV
camera which includes infrared illuminators for
clear picture in low/no light conditions; powered by
the RE-1 CCM-2: RE-2 field upgradable color
CCTV camera; powered by the RE-2 CPDM-1 Digital
Modulator: Converts camera video signal
to a UHF or CATV channel television signal AM-KP:
auxiliary wired keypad used for accepting entry
codes to control a second door or gate Block Coded
Transmitters: programming remotes into
the RE-1’s integral radio receiver can be done with
just a few keystrokes
RE-2 Trim Rings
• For the RE-2N use trim-ring P/N ACP00915
• For the RE-2SS use trim-ring P/N ACP00917
|
