Ideal for controlling orderly flow of foot traffic in both indoor and outdoor settings ( matching gate to our High-Security Full-Height Single and Tandem Turnstiles)
• Hot dipped galvanized carbon steel
• Polyester enamel on carbon steel (standard color is black/ other colors available upon request)
• Our signature 304 Stainless steel/ No. 4 satin finish
HS336-ADA
Manual Passage Gate
304 Stainless, No. 4 Satin finish (shown)
Also available in hot-dipped galvanized or
powder coat finishes.
Design & Construction:
• Designed for secure operation with asthetics in mind
• Featuring fully welded exterior components
• Minimal exposed hardware
• Heavy gauge materials meeting ASTM standards
Measures:
HS336-ADA
Size of opening (pedestrian clearance)
HS336-ADA 36 " (914mm)
Frames and Door Jam
2"x2" (51mm x51mm) 11 guage box tubint
Exterior Height
91" (2331mm)
Interior Height
88 1/2 " (2248mm)
Interior Tubing Sizes
1 1/2" Diameter 14 Guage (2248mm)
1 3/4" Diameter 14 Guage (44mm)
1 3/4" Diameter 11 Guage (44mm)
Features:
Swing Gate equipped with outdoor rated electronic strike lock and automatic door closer
Keylock- Control direction of travel manuallyby key ( to lock or unlock) or may be used to overide electronic controls.
Electrical Specifications:
Command module input 110-240
VAC (2 amp-1 amp) 50-60 Hz; control voltage 24 VDC.
All electrical components are
UL recognized and CSA certified.
Standards and Codes:
Austenitic stainless steel:
ASTM A240, A249, A276
Hot rolled steel:
AISI C-1020, AISI C-1018
Hot dipped galvanizing:
ASTM A-143, ASTM A-153-80
Stainless steel fasteners:
ASTM A-320
American Welding Society (AWS)
Standard D 1.1
Warranty:
Units are warranted against defects in materials and workmanship for a period of one year from date of
delivery. See warranty information for specific details.
The High-Security Series
