WI-200
Fingerprint Time & Attendance and Access
Control Terminal
* Professional Design: Elegant workmanship,
Multi-identification methods, can meet
user’s individual requirement: Proximity
card, fingerprint, password, of which
functions can be chosen freely combined for
identification.
* Multi-group network communication: RJ45
Ethernet, RS232, RS485.
* Standalone function: it is suitable the
application of inconvenient remote network,
adopt U disk to download and upload time
attendance record& photos conveniently.
* Build in embedded TCP/IP protocol, 100M
high-speed network to transmit the data.
Support the real-time transfer of the time &
attendance data, using steady internet
platform which has improved the reliability
of the time & attendance data.
* Multi-item auxiliary functions: Meeting
Notice, Birthday Prompt, sharp Hour ring
prompt, power on and off at schedule time,
advertisement broadcast.
* Huge capacity memory: The maximum storage
is 1,500 fingerprints, store 30,000 records;
EMS memory can be distributed and extended
dynamically.
* Incorporated the advanced LINUX Embedded
operation system, 24 hours continuous
operation; the terminals are steady and
credible.
* Adopt the worlds most advanced fingerprint
sensing technology and algorithms, fast
identification speed, the FAR rate is
0.0001% .
Technical Specification
User Capacity：1500
Transaction Capacity：30000
Platform：M500 (8M Flash)
CPU：32bit 6001 Microprocessor
Algorithm：2007 Version Finger VX8.0
Sensor: SecuGen/Optical sensor.
Identification：1:1 or 1:N
Verification Time：1:1 ≤1 sec
o 1:N-≤2sec (1500users)
TFT dimension: 3.5"
TFT display: 65,000 true color
TFT resolution: 320*240
I/O Interface：RS232/485, TCP/IP, USB
Host, USB Client
Standard Function：Access control
(wiegand26 In and wiegand26 out, time zone),
8 user-defined Function Key, Short Message,
Schedule Bell, T9.
Options：Antipass-back, WIFI, HID card,
MiFare card, ID card, Photo-ID,
Multi-Language, 1GU-disk, 12VUPS
Power：12V - 3A DC
Weight：2 KGs.
Operating Temperature : 0°C - 40°C
Operating Humidity : 20% - 80% |
